- Description
- Reviews
Features
- Fully featured rotary laser has Dual Dial-In Slope, CORE18V power, Bluetooth® connectivity, uCAL user-calibration and more
- Dual Dial-In Slope allows slope angle adjustment on both the X and Y axes
- Dual Power Source for extended runtime and option of a 4.0 Ah CORE18V battery or a battery adapter with four (D) cell batteries
- Durable design engineered with a cage rubber overmold and an innovative handle design to stand up to the toughest jobsites; built to IP68 dust- and water-protection standards
- Bluetooth® connectivity connects to a mobile device, linking to the free Bosch Leveling Remote App, to control sleep mode, Dual Dial-In Slope, and more
- uCAL user-calibration guiding the user step-by-step to confirm tool status or calibrate the rotary laser to ensure accuracy on the jobsite
- Long working range range of up to 4,000 Ft. with laser receiver, the laser accuracy of up to ±1/16 In. at 100 Ft. in horizontal mode and ±1/8 In. at 100 Ft. in vertical mode
- Vertical-beam functionality provides a vertical beam at 90° point for layout, squaring and plumb applications
- Electronic self-leveling allows for easy setup and use on the job
- Disturbance monitor indicates if tool position changes, ensuring consistent leveling accuracy
- Variable-speed and scan-angle selection allows for maximum visibility at different lighting conditions
- Comprehensive kit includes a remote control, 18V 4.0 Ah battery and charger, alkaline battery adapter, wall mount, laser receiver, aluminum tripod, sturdy grade rod and durable hard carrying case
What's in The Box
- GRL4000-80CHV 18V REVOLVE4000 Connected Self-Leveling Horizontal/Vertical Rotary Laser
- LR40 Laser Receiver with Bracket
- GBA18V40 18V CORE18V Lithium-Ion 4.0 Ah Compact Battery
- 18V Battery Charger
- BA1 Alkaline Battery Adapter
- 4 D Batteries
- 4 AA Batteries
- BT170 Heavy-Duty Aluminum Tripod
- GR13 13 Ft. Grade Rod
- WM6 Wall Mount
- RC5 Remote Control
- Carrying Case
- Owner's Manual
Warranty
- 1 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
SKU | GRL4000-80CHVK-BAT |
Brand | Bosch |
Power | Cordless |
Volts | 18V |
IP Rating | IP 68 |
Laser Beam Color | Red |
Laser Diode | 635 nm, < 1mW |
Leveling Type | Self-Leveling, Up to 5° |
Material | Plastic Composite |
Mount Threading | 5/8-11 |
Operating Temperature | 14° F / -10° C ~1 22° F / 50° C |
Range | Up to 4,000-ft. |
Works With | Laser Receivers LR 1 G, LR 30, LR40, LR 50 Tripods BT160, BT170HD, BT300HD, BT 150 Grade Rods GR500 Mounts and Positioning Devices WM 4 |
Length | 12.8" |
Width | 7.4" |
Height | 11.0" |
Weight | 8.2lb |
