Features
- Large precision ground cast iron table
- Magnetic switch w/ thermal overload protector
- Shielded andamp; lubricated ball bearings
- Powder coated paint
- Built-in 4 dust port
- Split adjustment fence
- Pedestal switch
- Integrated mobile base
What's in The Box
- W1763 SHOP FOX 2-1/2 HP Shaper
- Owner's Manual
Warranty
- 2-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Motor: | 2 HP, 220V, single-phase, TEFC |
| Dust Ports: | (2) 4 |
| Table size: | 26-7/8 x 12 |
| Table travel: | 3-3/4 Vertical, 5 Horizontal |
| Aux. table size: | 10 x 11-1/2 |
| Aux. table travel: | 10 |
| Sanding belt size: | 6 x 89 |
| Sanding belt speed: | 3150 FPM |
| Sanding belt oscillation stroke: | 3/4 |
| Drive drum diameter: | 7 |
| Idler roller diameter: | 3-7/8 |
| Platen with graphite pad: | 6-3/4 x 30-1/4 |
| Platen tilt: | 0Degree through 90Degree (5Degree scale) |
| 3 spindle drums: | 1-1/2, 2, 3 x 4-1/2 high |
| Item Weight: | 443 pounds |
| Product Dimensions: | 47.2 x 43.3 x 29.8 |
